1.5 ton electric forklift is an ideal choice for material handling, designed for warehouses, factories and logistics centers. It is driven by environmentally friendly batteries, has zero emissions and low noise, adding a sense of tranquility and greenness to your working environment.
Core highlights:
Efficient load: 1500 kg
Lifting height: 3000MM
Safety frame height: 2140MM
Minimum turning radius: 2250MM
|
Vehicle parameters |
|||
|
Model |
CPD1.5 |
Tire type (drive/steering) |
Solid rubber tire |
|
Power Type |
Lead acid battery |
Steering Tire Size |
5.00-8 |
|
Operation type |
Riding style |
Driving Tire Size |
6.50-10 |
|
Load(kg) |
1500 |
Front Wheelbase(mm) |
1050 |
|
Load center distance(mm |
500 |
Steering Wheelbase(mm) |
880 |
|
Front Overhang(mm) |
400 |
Drive motor power(kw 60min) |
3 |
|
Wheelbase(mm) |
1550 |
Lifting motor power(kw 15min) |
M |
|
Mast tilt angle (aβ) |
6/8 |
Battery voltage(V/ah) |
60/70 |
|
Minimum Ground Clearance(mm) |
100 |
Controller |
AC |
|
Maximum lifting height(mm) |
3000 |
Working pressure(mpa) |
15 |
|
Dimension L/W(mm) |
2330*1200 |
Maximum climbing angle(°) |
15 |
|
Mast lifting/unlifting height(mm) |
3550/2080 |
Driving brake type |
Oil brake |
|
Fork size L/W/T(mm) |
1070 |
Parking brake type |
Mechanics |
|
Minimum turning radius(mm) |
2250 |
Drive control type |
Electric |
|
Safety rack height(mm) |
2140 |
Steering type |
Hydraulic steering |
|
Weight (including battery)(kg) |
2150 |
Noise level |
68 |
|
|
|
|
|
